CWZ orizontal bilge ballast ponp
● Series: CWZ
● Type:Self –priming centrifugal pump
● Application: bilge, water
● Advantage: good self-priming performance
Dekri teren
Aplikasyon ponp seri CWZ
Ponp CWZ se yon sèl etap, yon sèl aspirasyon, fen-aspirasyon ponp santrifujeur maren.
Seri ponp sa a te konstwi-nan aparèy pwòp-prime ak bon pèfòmans nan pwòp tèt ou-primer (san ekipman adisyonèl pwòp tèt-priming) epi li travay kòm ponp refwadisman maren, ponp sanitè, ponp dife, G/S (ponp sèvis jeneral), ponp ballast bilge
Aplikasyon ponp seri CWZ
Aplikab pou transfè dlo lanmè ak tanperati dlo fre pa plis pase 85 degre
Materyèl
1. pump casing/casing cover/drain cover/suction cover: bronze(sea water) or cast iron(fresh water)
2. Impeller/wear ring: bronze,
3. shaft, shaft sleeve and key: stainless steel
Estrikti


1. Shaft seal: mechanical seal, material: SIC(silicon carbide),hard alloy and ceramics, double face mechanical seal for big power pump.
2. Priming: built-in self-priming casing and cover, with check valve in the discharge pipe, suction head about 4-5meter
3. Coupling: flexible coupling type, material in carbon steel, or direct coupled as optional.
4. Bearing: motor side, two enclosed antifriction bearing, lubricated by grease; pump side, two deep groove rolling ball bearing, lubricated by oil in oil bath.
5. Accessory: motor terminal box, lifting hooks, grease nipple, oil cup, air vent plug, drain plug, gauge connection plug and so on.
Paramèt prensipal
Non seri | CWZ |
Non pwodwi | Marin orizontal pwòp tèt -priming santrifujeur ponp |
Karakteristik | Well fixed and beautifully shaped and have high self-priming function, can be installed and used easily |
Kapasite | 8-550 m3/h |
Tèt | 15-120 m |
Vitès | 2900 /3450 r/min |
Pouvwa motè | 315KW (Maksimòm) |
Aplikasyon | Bilge, ballast, kontwòl dife, refwadisman, sanitè |
Tanperati | Max.85 degre |
Sètifikasyon | CCS, ABS, BV, etc. |
